Large-space fire extinguishing system-Yingkou New Shanying Alarm Equipment Co., Ltd.

Serial number号	Equipment name	Equipment model	Illustration marking
1	Automatic tracking and positioning jet fire extinguishing device	YKS25/30/35	①
2	Simulated end water test device	ESIP-YKS-MD25	②
3	Solenoid valve	ZSCF-50	③
4	Manual gate valve	DN150	④
5	Manual gate valve	DN100	⑤
6	Manual butterfly valve	DN80	⑥
7	Manual butterfly valve	DN50	⑦
8	High-level water tank		⑧

Go Back

Schematic diagram of the pipeline network for the YKS50/55 automatic tracking and positioning jet fire extinguishing system
